BEP 1002204 Marine Grade 12V 85A Continuous Duty SPST Solenoid Switch
- BEP Marine Grade 85A Continuous Duty Remote Solenoid Switch
- Continuous Rating: 85 Amp
- Intermittent Rating: 750A make, 100A break, 10 sec On, 30 min. Off
- Normally Open Contacts, SPST
- Housing: Plated steel
- Terminals: Copper 5/16"-24 thread, hex nuts and lock washers included.
- Coil, ignition, and ground terminals: Steel 10-32 thread, hex nuts and lock washers included.
- Bracket mounting holes 5/16" x 19/32" on 2-13/64" centers (56mm).
- Can be used with Electro-Scan MSDs and other high-amp circuits with remote operation.
- Manufacturer: BEP
- Model Number: Continuous Duty Solenoid
- Part Number: 1002204
- Also Known As:
