Icom IC-M220 Boat Marine IPX7 Class D DSC VHF Radio Transceiver

  • Sale
  • $229.95
  • 1 available
  • Icom IC-M220 Boat Marine IPX7 Class D DSC VHF Radio Transceiver
  • Features:
    • Compact body for easy installation in limited space
    • Powerful front mount speaker
    • Built-in Class D DSC
    • HM-237B detachable hand microphone supplied
    • IPX7 submersible construction
    • AquaQuake
    • Common NMEA interface for external GPS/NAV connection
    • Tag Scan and Favorite Channel functions
    • Dualwatch and Tri-watch functions
    • Priority Scan function
    • Display and keypad backlighting
    • External speaker connection
  • Specifications:
    • General:
      • Frequency Range: Tx: 156.025–157.425 MHz, Rx: 156.050–163.275 MHz, CH70: 156.525 MHz
      • Usable Channels: USA, CAN, INT, WX channels
      • Type of Emission: 16K0G3E (FM), 16K0G2B (DSC)
      • Power Supply Requirement: 13.8 V DC nominal (11.7–15.9 V DC)
      • Current Drain (at 13.8 V DC): TX 25W Output: 5A, RX AF Max.: 1.2A
      • Operating Temperature Range: –20°C to +60°C; –4°F to +140°F
      • Antenna Impedance: 50 Ω (SO-239)
      • Dimensions (WxHxD): 6.2” X 2.6” X 4.3” (156.5 X 66.5 X 110.1 mm)
      • NMEA Formats: Input: RMC, GGA, GNS, GLL, VTG, Output: DSC, DSE, RMC, GSA, GSV
    • Transmitter:
      • Output Power (at 13.8 VDC): 25W, 1W
      • Max. Frequency Deviation: ±5 kHz
      • Frequency Tolerance: ±5 ppm
      • Spurious Emissions: Less than –60 dBc
    • Receiver:
      • Sensitivity: Main: –13 dBµ typ. (12 dB SINAD), DSC: –5 dBµ emf typ. (1% BER)
      • Squelch Sensitivity: Less than –10 dBμ
      • Adjacent Channel Selectivity: Main: More than 68 dB, DSC: More than 68 dBμ emf (1% BER)
      • Intermodulation: Main: More than 63 dB, DSC: More than 55 dBμ emf (1% BER)
      • Sensitivity: –14 dBμ typ. (at 12 dB SINAD)
      • Hum and Noise: More than 40 dB
      • Audio Output Power (at 10% distortion with a 4 Ω load): 4.5W typical
  • Manufacturer: Icom
  • Model Number: VHF Marine Transceiver
  • Part Number: IC-M220
