Midland Metal 12-060 12060 Brass 1/4” Female Inverted Flare X 1/4” MIP 90° Male Elbow Fitting
- Brass 1/4” Female Inverted Flare X 1/4” Male NPTF 90° Male Elbow Fitting
- Female Inverted Flare x Male NPTF: 1/4” x 1/4”
- Temperature Range: -65°F to +250°F (-53°C to +121°C) range at maximum operating pressures.
- Very low cost and reusable. Seats and threads are internal and protected. Compact, excellent vibration life. Short nut affords very close tube bends.
- Meets specifications and standards of ASA, ASME, SAE and MS (Military Standards).
- SAE# 040202
- Vibration: Excellent resistance.
- Applications: Hydraulic brake, power steering, fuel lines and transmission cooler lines, LP and natural gas.
- Used With: Copper, brass, aluminum and steel hydraulic tubing that can be flared.
- Manufacturer: Midland Metal
- Model Number: Elbow Fitting
- Part Number: 12-060, 12060
- Also Known As:
- 04349-0404, 122440, 149-4B, 1494B, 2432X4, 2434X4, 249IF-4-4, 400-44, 402x4x4, 49I-4B, 49IF-44, 6944, IF49-4-4, S249IF-4-4
